Injection Molding Supplies

13X 1/8" bead type desiccant is for screens with a 4 x 8 mesh size. The actual bead size varies from .093 to .185. Because of the larger pore size of 13X it has a higher absorbency rate then 4A but it is more subject to contamination. Price is per Pound.

The HRCH1-2-10 240 Volt 10 Amp stand-alone hot runner temperature controller packages all of the features of our HRC-1-2 modular temperature controller into a self contained unit for simpler installations such as hot sprues and barrel heaters.

The High Power Cold Gun produces twice the airflow of the standard Cold Gun. The unit is 10" OAL with a 3/8 NPT female connection for outlet. The unit mounts with an attached magnetic base. A Cold Gun is designed to use full line pressure of 80-100 PSIG.

OS206 200 series Brass Water Coupler with a 1/4" water passage. The coupler body is non-valved with a straight 3/8" O.D. standard hose barb .92" in length. This 200 series brass water coupler has a body length of 1.15" and body diameter of .67".

30mm Engel Screw Tip 3 piece free flow design. Manufactured with CPM-9V super wear resistance tool steel to insure superior wear resistance. 30mm check ring diameter with a M12 x 1.75 Right Hand thread on the stud. Please specify Overall Length.

42910 Slide mold shield is a unique rust preventive formulation. Designed, through a special ultra-dry spray package, to deliver a dry mist spray which will not penetrate into moving mold parts, including ejector pin holes, slides, cams, etc.

DP6AL This type DP 6" aluminum cam & groove male adapter is used to plug off the female coupler. Camlock cam and groove couplings work well in dry bulk and low pressure liquid applications. The max. working pressure is 75 PSI.

Overnite Supplies coil heater with .875" inside diameter 3.13" in length and type J grounded thermocouple. It is 240 volt 550 watts, profiled heat with 36" type J thermocouple and 36" fiberglass sleeved leads. The leads run parallel to the center line.

TAC1250A Tops-All machined 13" extra heavy duty closed-toe mold clamp. This machined mold clamp is 13" overall length and is an closed-toe design with a 5 1/2" slot length and will accept a 1 1/4" clamp bolt.
